Head Type | HEX NUT |
Head Profile | STANDARD |
Drive Style | EXTERNAL HEX |
System of Measurement | INCH |
Thread Direction | RIGHT HAND |
Thread Type | INCH |
Thread Fit | 1" UNC |
Material | ALLOY STEEL |
Hardness | 26-34 HRC |
Thread Size | Length | Threading | Min. Thread Length | Thread Spacing | Drive Size | Tensile Strength | Specificaion Met | Grade | Box Qty | PPC | Price/100 (in INR) |
Price/100 (in USD) |
Stock | |
1" UNC | - | - | 0 | Coarse | A/F 1.5" | - | ASME B18.2.2 | 8 | 50 | 4 | 7139 | 90 | 1383 | |
1/2" BSF | - | - | - | Fine | A/F 0.820" | - | BS 1083 | P | 200 | 8 | 1044 | 13 | 0 | |
1/2" UNC | - | - | 0 | Coarse | A/F 0.750" | - | ASME B18.2.2 | P | 200 | 8 | 947 | 11 | 22117 | |
1/2" UNF | - | - | 0 | Fine | A/F 0.750" | - | ASME B18.2.2 | P | 200 | 8 | 947 | 11 | 0 | |
3/4" UNC | - | - | 0 | Coarse | A/F 1.125" | - | ASME B18.2.2 | 8 | 200 | 8 | 3920 | 49 | 0 | |
3/8" BSF | - | - | - | Fine | A/F 0.600" | - | BS 1083 | P | 500 | 8 | 419 | 5 | 0 | |
3/8" UNC | - | - | 0 | Coarse | A/F 0.563" | - | ASME B18.2.2 | P | 500 | 8 | 419 | 5 | 923 | |
3/8" UNF | - | - | 0 | Fine | A/F 0.563" | - | ASME B18.2.2 | P | 500 | 8 | 419 | 5 | 124350 | |
M4 | - | - | - | Coarse | A/F 7.0 | - | ISO 4032 / IS 1364-3 | 8 | 1000 | 30 | 112 | 1 | 49870 | |
M5 | - | - | - | Coarse | A/F 8.0 | - | ISO 4032 / IS 1364-3 | 8 | 1000 | 4 | 139 | 1 | 25600 | |
5/16" BSF | - | - | - | Fine | A/F 0.525" | - | BS 1083 | P | 500 | 10 | 283 | 3 | 0 | |
5/16" UNC | - | - | 0 | Coarse | A/F 0.5" | - | ASME B18.2.2 | P | 500 | 10 | 283 | 3 | 23370 | |
5/16" UNF | - | - | 0 | Fine | A/F 0.5" | - | ASME B18.2.2 | P | 500 | 10 | 283 | 3 | 0 | |
5/8" BSF | - | - | - | Fine | A/F 1.010" | - | BS 1083 | P | 200 | 0 | 2359 | 29 | 0 | |
5/8" UNC | - | - | 0 | Coarse | A/F 0.938" | - | ASME B18.2.2 | 8 | 200 | 4 | 1991 | 25 | 19575 | |
5/8" UNF | - | - | 0 | Fine | A/F 0.938" | - | ASME B18.2.2 | 8 | 200 | 4 | 283 | 30 | 0 | |
M6 | - | - | - | Coarse | A/F 10.0 | - | ISO 4032 / IS 1364-3 | 8 | 1000 | 10 | 193 | 2 | 29915 | |
7/16" BSF | - | - | - | Fine | A/F 0.710" | - | BS 1083 | P | 200 | 10 | 931 | 11 | 0 | |
7/16" UNC | - | - | 0 | Coarse | A/F 0.688" | - | ASME B18.2.2 | P | 200 | 10 | 931 | 11 | 0 | |
7/16" UNF | - | - | 0 | Fine | A/F 0.688" | - | ASME B18.2.2 | P | 200 | 10 | 931 | 10 | 9595 | |
7/8" UNC | - | - | 0 | Coarse | A/F 1.312" | - | ASME B18.2.2 | 8 | 125 | 10 | 6386 | 80 | 0 | |
M8 | - | - | - | FINE | A/F 13.0 | - | ISO 4032 / IS 1364-3 | 8 | 500 | 10 | 252 | 3 | 15160 | |
M10 | - | - | - | Coarse | A/F 16.0 | - | ISO 4032 / IS 1364-3 | 10 | 300 | 4 | 565 | 7 | 66895 | |
- | - | - | FINE | A/F 16.0 | - | ISO 4032 / IS 1364-3 | 10 | 300 | 4 | 558 | 7 | 0 | ||
- | - | - | FINE | A/F 16.0 | - | ISO 4032 / IS 1364-3 | 8 | 300 | 4 | 489 | 6 | 0 | ||
- | - | - | Coarse | A/F 16.0 | - | ISO 4032 / IS 1364-3 | 8 | 300 | 4 | 489 | 6 | 0 | ||
- | - | - | FINE | A/F 16.0 | - | ISO 4032 / IS 1364-3 | 8 | 300 | 4 | 489 | 6 | 4495 | ||
M12 | - | - | - | FINE | A/F 18.0 | - | ISO 4032 / IS 1364-3 | 8 | 200 | 4 | 763 | 9 | 0 | |
- | - | - | FINE | A/F 18.0 | - | ISO 4032 / IS 1364-3 | 8 | 300 | 4 | 763 | 9 | 0 | ||
- | - | - | FINE | A/F 18.0 | - | ISO 4032 / IS 1364-3 | 10 | 200 | 4 | 869 | 11 | 0 | ||
- | - | - | Coarse | A/F 18.0 | - | ISO 4032 / IS 1364-3 | 8 | 200 | 4 | 763 | 9 | 181365 | ||
- | - | - | Coarse | A/F 18.0 | - | ISO 4032 / IS 1364-3 | 10 | 200 | 4 | 869 | 11 | 10520 | ||
M14 | - | - | - | Coarse | A/F 22.0 | - | ISO 4032 / IS 1364-3 | 10 | 125 | 10 | 1519 | 19 | 1860 | |
M16 | - | - | - | Coarse | A/F 24.0 | - | ISO 4032 / IS 1364-3 | 10 | 200 | 4 | 1877 | 24 | 44190 | |
M18 | - | - | - | Coarse | A/F 27.0 | - | ISO 4032 / IS 1364-3 | 10 | 150 | 4 | 2902 | 36 | 105 | |
M20 | - | - | - | Coarse | A/F 30.0 | - | ISO 4032 / IS 1364-3 | 10 | 100 | 4 | 3611 | 46 | 13700 | |
M22 | - | - | - | Coarse | A/F 32.0 | - | ISO 4032 / IS 1364-3 | 10 | 75 | 4 | 5058 | 64 | 5079 | |
M24 | - | - | - | Coarse | A/F 36.0 | - | ISO 4032 / IS 1364-3 | 10 | 50 | 4 | 6045 | 80 | 7195 | |
M27 | - | - | - | Coarse | A/F 41.0 | - | ISO 4032 / IS 1364-3 | 10 | 30 | 4 | 10616 | 134 | 3955 | |
M30 | - | - | - | Coarse | A/F 46.0 | - | ISO 4032 / IS 1364-3 | 10 | 25 | 4 | 15286 | 193 | 2506 | |
M33 | - | - | - | Coarse | A/F 50.0 | - | ISO 4032 / IS 1364-3 | 10 | 25 | 4 | 21030 | 266 | 1092 | |
M36 | - | - | - | Coarse | A/F 55.0 | - | ISO 4032 / IS 1364-3 | 10 | 15 | 4 | 27148 | 343 | 1542 | |
M42 | - | - | - | Coarse | A/F 65.0 | - | ISO 4032 / IS 1364-3 | 10 | 10 | 4 | 45530 | 576 | 875 |
